Statement
from the customer
"We definitely wanted to build a Thoma house and our architect recommended the heating system from HALLER. We enjoy the pleasant warmth of the HALLER infrared heaters and are very satisfied."
Figures, data, facts
| Energy independence components | Photovoltaic system, HALLER infrared heaters |
| Year of construction | 2019 |
| Move-in date | 2020 |
| Type of building | Wooden house |
| Energy standard | KfW 70 |
| Roof insulation | Holz100 solid element + 18 cm rafters, 3.5 wood fibre |
| Outer wall thickness | Holz100 30.6 + 6 cm insulation |
| U-value of envelope (W/m2K) | Outer wall = 0.221; windows = 0.81; roof = 0.161 |
| Ventilation system | None |
| PV system capacity | 9 kWp |
Consumption values
| Floor area | 180 sqm |
| Heated area | 180 sqm |
| Connected load | 8.65 kW |
| Number of heaters | 11 |
| Number of persons | 5 |
| Hot water | Air heat pump |
| Supplementary heating | Basic furnace |
